14,000 to 21,000 GVWR, available in tag-along or gooseneck. Features E-Z crank beavertail, tandem , or triple axles, 16″ radial tires, 8 bolt hubs.
Models Available: 25TDOWC 25GDOWM 29TTAWC 29GTAWC
|
Deck Over Series Flatbed Trailer Specifications |
|
|
Deck Length |
25’ & 29’ |
|
Overall Width |
102” |
|
Axles |
Tandem (2) 7,000#, Triple (3) 7,000# U-Lube |
|
Brakes On All Axles |
Electric |
|
Tire Size |
235/80R16 Radial |
|
Pattern |
8 On 6-1/2” |
|
Adjustable Coupler |
Standard |
|
Hitch Size |
2 5/16” Ball Coupler or Lunette Eye GN – 2 5/16” |
|
Hitch Height |
20” – 28” |
|
Bed Height |
33 1/2” |
|
GVWR |
14,000# on 25’, 21,000# on 29’ |
|
Payload Capacity (Average) |
8,900# on 25’, 15,000# on 29’ |
|
Floor |
2” Treated Wood |
|
Front Jack |
12,500# |
|
DOT Lighting |
Standard |
|
Break-Away Kit with Battery |
Standard |
|
Cross Members |
3” Channel on 24” Center |
|
Frame Rails |
W8 I-Beam |
|
5’ Ramps |
Standard |
|
Stake Pockets |
Standard |
|
Flip-Up Ramps |
Standard |
|
Mesh Tailgate |
Option |
|
Full Primer & Paint |
Standard |
|
Three-Year Warranty |
Standard |
|
Sealed Beam Tail Lights |
Standard |
|
D-Rings |
Option |
* Specifications subject to change.
Trailer Specifications Sheet – View Specificaitons For All Trailers (PDF document)
Model Numbering Explanation.
