12,000# GVWR or 14,000# GVWR with 7K drop axles, 16” radials, 8 bolt hubs, heavy duty jack, 6” channel frame and tongue.
Models Available: 20TFHWS 20TFHSB 20TFHWB 20GFHWS 20GFHSB 20GFHWB
|
Frame Heavy Series Flatbed Trailer Specifications |
|
|
Deck Length |
20’ |
|
Overall Width |
102” |
|
Width Between Fenders |
81” |
|
Axles |
U-Lube 2 – 7,000# 4” Drop |
|
Brakes On All Axles |
Electric |
|
Tire Size |
235/80R16 Radial, 235/85R16 Radial, LRG on 14,000 # GVWR |
|
Pattern |
8 On 6-1/2” |
|
Adjustable Coupler |
Standard |
|
Hitch Size |
2-5/16” or Lunette Eye |
|
Hitch Height |
14” to 22” |
|
Bed Height |
23” |
|
GVWR |
12,000# & 14,000# |
|
Payload Capacity (Average) |
8,700# on 12,000 GVWR, 10,600# on 14,000 GVWR |
|
Floor |
12 Ga. Steel Tread Plate or 2” Treated Wood |
|
Front Jack |
12,500# |
|
DOT Lighting |
Standard |
|
Break-Away Kit with Battery |
Standard |
|
Cross Members |
3” Channel on 18” Center |
|
Frame Rails |
6” Channel |
|
5’ Ramps |
Standard |
|
Stake Pockets |
Standard |
|
Flip-Up Ramps |
Option |
|
Mesh Tailgate |
Option |
|
Full Primer & Paint |
Standard |
|
Three-Year Warranty |
Standard |
|
Sealed Beam Tail Lights |
Standard |
|
D-Rings |
2 Rings |
* Specifications subject to change.
